PRODUCT
Battery Pack
arrangement : 1P100S
Specification
- Rated Capacity : 150 Ah
- Nominal voltage : 320 V
- Voltage range : 250-365V
- Battery kwh : 48 kwh
- Weight : ≤ 370 kg
- Maximum Continuous Discharge Current : 150 A
- Pulse discharge current (30S) : 300A (90%SOC)
- Battery box whole size : ≤725 (W) ≤500(H) ≤900(L) mm.
Get a Quote
Get in Touch
HG02-015KW-001
Specification
- Nominal Voltage (V) : 155.4 V @0.2C
- Nominal Capacity (Ah) : 84 Ah
- Nominal Energy (Wh) : 13 kWh
- Dimension (mm) Width x Length x Height
(Stacked in two layers) : 620 x 882.5 x ~400mm. - Weight (kg) : ~280kg
Get a Quote
Get in Touch
MOTOR
Electric Vehicle Motor
MODEL
Rated/Max. Power
Rated/Max. Torque
Rated/Max. Speed
Applications
Voltage Range
Current Module
DMS120
60/120kW
635/1200N·m
900/3800rpm
5.5-6T Light Truck
450-750V
600A
MODEL
Rated/Max. Power
Rated/Max. Torque
Rated/Max. Speed
Applications Testest
Voltage Range
Current Module
TZ230XS25
25/60kW
133/350N·m
1800/4500rpm
11.5-2.5T Light Truck
200-450V
255A
MODEL
Rated/Max. Power
Rated/Max. Torque
Rated/Max. Speed
Applications Testest
Voltage Range
Current Module
TZ260XS60
60/110kW
358/950N·m
1600/4500rpm
3.5-4.5T Light Truck
450-750V
340A
MODEL
Rated/Max. Power
Rated/Max. Torque
Rated/Max. Speed
Applications
Voltage Range
Current Module
SDK290
105/165kW
500/1000N·m
2005/4000rpm
7-10T Light Truck
450-750V
420A
